Mitutoyo: An Unrivalled Manufacturer of Precision and Reliable Measurement Tools
Mitutoyo, a leading
metrology equipment manufacturer, has a long-standing reputation for producing
high-performance measuring instruments. Their innovative products also include
Mitutoyo plunger dial indicators, and precision measurement tools commonly used in
various industries for accurate linear measurement. These indicators are known
for their exceptional quality, reliability, and precise readings in multiple
applications.
Mitutoyo offers a wide
range of plunger dial indicators with different measuring ranges and dial sizes
for various tasks. The dial indicators include a dial face, a spring-loaded
plunger, and a rugged casing. The plunger extends and retracts in response to
linear movement, while the dial face displays the corresponding measurements. This
article briefly introduces the key features, benefits, and applications of the
Mitutoyo 543-400B digimatic dial indicator,12mm, highlighting its
specifications and measurement capabilities.
Mitutoyo 543-400B Digital Dial Indicator: A Brief Introduction
The Mitutoyo metric dialindicator is a battery-operated measuring tool designed for precise and
repeated measurement in a variety of applications. It has a maximum measurement
range of 12mm and a resolution of 0.01mm, allowing for accurate and detailed
readings. With high accuracy, it offers ±0.02mm precision, ensuring reliable
and consistent measurements.
Furthermore, the dial
indicator can measure from 0 to 12mm, making it suitable for a wide range of
tasks that require precise dimensional analysis. Its battery-operated nature
adds convenience and portability, making it a versatile tool for professionals
in various settings.
Mitutoyo 0.01 mm Resolution Metric Dial Indicator: Key Features and Benefits
With its advanced and
unmatchable features and user-friendly design, the bespoke instrument offers exceptional
features and benefits, such as:
Superior Measurement
Accuracy: The Mitutoyo 543-400B
digital dial indicator is renowned for its exceptional accuracy and impressive
±0.02 mm tolerance. This high level of precision ensures reliable and consistent
measurements, making it a perfect measuring tool for demanding utmost accuracy
applications.
Wide Measurement
Range: With a measurement range
of 0 to 12 mm, the 543-400B digimatic dial indicator from Mitutoyo offers
versatility in measuring small components or larger parts. This indicator
provides the flexibility needed to accommodate different measurement
requirements.
High Resolution: The dial indicator
boasts a 0.01 mm resolution to obtain detailed measurements easily. This fine
resolution is crucial when working with intricate or delicate parts requiring
precise analysis.
Battery Operation: Featuring a
battery-operated design, the Mitutoyo indicator operates without needing an
external power source. This feature offers convenience, portability, and flexibility
in various working environments.
Digimatic Technology: Equipped with Mitutoyo's
renowned Digimatic technology, this dial indicator ensures accurate and
reliable digital measurement readings. The digital display eliminates the need
to manually interpret dial graduations, reducing human error and saving time.
User-Friendly
Interface/Display Functions: The Mitutoyo’s 543-400B dial indicator is designed with
user convenience in mind. The intuitive interface and easy-to-read digital
display make it simple to operate. The indicator also features buttons for
zero-setting, inch/metric conversion, and data hold functions, further
enhancing usability.
Durable Construction: Durability is a key
aspect of the Mitutoyo 543-400B digital dial indicator. This measuring
instrument is constructed with high-quality materials and can withstand the
rigours of demanding work environments. Its robust design ensures longevity,
providing reliable and long-term use.
Data Output Capability: The Mitutoyo metric dial
indicator offers data output functionality for advanced data processing and
analysis. This feature lets users connect the indicator to external devices
such as computers or data collectors. This results in enabling seamless
integration with measurement systems and data logging software.
Calibration and
Traceability: Mitutoyo is known for its commitment to accuracy and
quality. The digimatic dial indicator 543-400B is calibrated to international
standards. Mitutoyo’s regular calibration services or authorized service centers,
such as Enrgtech, further guarantee the device's accuracy and reliability.
How to Use the Mitutoyo, 0 → 12 mm Metric Dial Indicator?
Use the indicator by
following the given steps:
Step 1: Set
Up the Indicator
Securely mount the dial indicator
on a stable surface and ensure that the indicator is aligned with the surface
you want to measure.
Step 2: Zero
the Indicator
Set the dial face until
the indicator reads "0", setting the initial reference point.
Step 3:
Position the Contact Point
Place the indicator's
contact point on the surface or object and ensure it makes firm contact without
any lateral or tilting movement.
Step 4: Take
Measurements
Gently apply pressure to
the contact point to ensure consistent contact with the surface. Observe the
dial face indicating the measured object's displacement or movement.
Step 5: Read
the Measurements
Read the value indicated
on the dial face. The numbers on the dial correspond to millimeter increments.
Step 6:
Record Measurements
Take note of the
measurements for your records or further analysis.
Step 7: Reset
the Indicator
After your measurements,
reset the dial indicator by returning to the zero position for subsequent use.
Important Note: It's crucial to handle
the dial indicator with care and avoid applying excessive force to prevent
instrument damage or inaccurate readings.
Mitutoyo Metric Dial Indicator, 0 → 12 mm: Versatile Applications
The Mitutoyo 0 to 12 mm dial indicator finds applications
in various industries and sectors. Whether in manufacturing, engineering,
research, metalworking, or quality control and inspection, this instrument is
used to measure precisely:
- Machined parts’
accuracy.
- Small
distances.
- Screws’
tightness.
- Automotive and
Aerospace parts.
- Holes and
shafts’ diameters.
- Medical
equipment diameters.
- Dimensions like
length, depth, width, etc.
- Thin materials’
thickness.
- Surface
flatness.
The Final Words
Mitutoyo plunger dial indicators are trusted by professionals worldwide for their accuracy,
reliability, and longevity. The Mitutoyo 543-400B dial indicator stands as a
testament to the company's dedication to precision and reliability. With its
exceptional accuracy, wide measurement range, and advanced features, the
bespoke measuring instrument provides users with a competent and user-friendly
tool for achieving accurate measurements. Whether in manufacturing, automotive,
aerospace, or any industry requiring precise measurements, Mitutoyo 543-400B
plunger dial indicator is a go-to choice for professionals demanding top-notch
metrology equipment.
